Comfort sensor for swing & revolving doors
Technology Active infrared


The EYE-TECH is a presence active infrared sensor operating by distance measuring. Mounted on the leaves of swing and revolving doors, it offers a basic safety for the users.


Reliable detection

Reliable detection thanks to the “anti-masking” option irrespective of the texture or the colour of the object to be detected.

Extendable detection area

Possibility to extend the detection area by adding “slave” modules.

Safety for low energy doors

Additional safety device for low energy doors used by people with disabilities.

Focused protection zone

Protection of people by covering an area of 10 cm in front of the leaf 2 m high with a single active infrared spot.

Table of specifications


Active Infrared with background suppression


Detection distance:

0.7 m to 2.5 m (adjustable by linear movement swivelling cam)


Module inclination angle:

0° - 5° - 10° - 15° - 20° - 25°


Diameter of the infrared beam:

0.13 m @ 2 m


Detection mode:

Presence (and movement)


Detection duration (presence):



Response time:

< 50 ms


Special inputs:

System inhibition


Supply voltage relay output:
Supply voltage transistor output:

12 to 24 V AC/DC ±10%
12 to 30 V DC ±10%


Mains frequency:

50 to 60 Hz


Power consumption Master ON:
Slave ON:
Master OFF:
Slave OFF:

60 mA maximum
40 mA maximum
30 mA maximum
30 mA maximum


Standard output
Relay contact ratings (max voltage):
Relay contact ratings (max current):
Max. switching power:

Switch-over relay (voltage free contact)
60 V DC /125 V AC
1 A (resistive)
30 W (DC) / 60 VA (AC)


Optional output
Max. voltage:
Max. current:

Open collector transistor
30 V DC
100 mA (protection against short-circuits)


Output holding time:

0.1 s to 4.5 s (adjustable)


Temperature range:

–20°C to +50°C



340 - 700 - 900 mm (L) × 43.5 mm (H) × 47.5 mm (D)



Aluminium, ABS and Plexiglas


Colour of the box:

Natural aluminium (black or chrome optional), black front side


Connection sheath:

0.5 m


Norm conformity:

EN 12978, EN ISO 13849-1:2008 Performance level «c» CAT.2
(under the condition that the door control system monitors the sensor at least once per door cycle)


Specifications are subject to changes without prior notice – Measured in specific conditions.
